مشخصات
| Port | 4GE+VOIP+1 USB+WIFl5+G/EPON |
|---|---|
| LED | POWER+PON/LOS+NET +LAN + VOIP+WiFi + WPS + USB |
| Button | Power + Reset +WIFl+WPS |
| Flash & Memory | Flash: 256MB; Memory: 512MB |
| Power Supply | 12V/1.5A |
| Power Consumption | <8W |
| Environment Standard | Operating Temperature: -5-45°C |
| Environment Friendly | RoHs, CE, CCC |
| Weight | 0.35KG |
| Size (W*D*H) mm | 190mm*135mm*33mm |
| Module type | Class B+, SC/UPC |
| wavelength | UP 1310nm,Down 1490nm |
| TX Optical power | 0.5-4dbm |
| RX Optical sensitivity | -28dBm |
| Transmission distance | 0-20km |
| Transmission rate | EPON: Upstream 1.25Gbps/Downstream 1.25Gbps |
| LAN Interface type | RJ45 ( 10/100/1000M bps ) |
| VOiP | RJ11 |
| USB | USB2.0 |
| WIFI | Dual-band WIFl5 AC1200 (2 x2 MIMO (2.4G&5G)) |
| WiFi Protocol | 2.4GHz supports 802.11 b/g/n |
| Transmit Power | 2.4G 1 00mW; SG 200mW |
| Antenna Gain | 5dBi |
| Antenna | Dual-antenna MIMO (2.4G&SG) |
| WLAN Access Capability | 32 clients |
| Channel | 2.4GHz (channel 1-13) |
| WLAN Security Function | WPA-PSK, WPA2-PSK, WPA3 WPA-PSK/WPA2-PSK AES, AES+ TKIP |
| Air Speed | 300 Mbps (2.4GHz); 867 Mbps (5GHz) |
