مشخصات
| Resolution | 2MP |
|---|---|
| Sensor | 1/2.8", 2.0 megapixel, CMOS, progressive scan |
| Min. Illumination | Colour: 0.001 Lux (F1.5, AGC ON) 0 Lux with IR |
| Day/Night | IR-cut filter with auto switch (ICR) |
| Shutter Time | Auto/Manual, 1 ~ 1/100000s |
| WDR | 120dB |
| S/N | >52dB |
| Lens | 4.5 ~ 148.5mm, AF automatic focusing and motorized zoom lens |
| Digital Zoom | 16 |
| Optical Zoom | 33 |
| Field of View (H) | 56.2°~2.6° |
| Field of View (V) | 33.5°~1.4° |
| Field of View (D) | 69.1°~3.1° |
| IR Range | Up to 150m (492 ft) IR range |
| Wavelength | 850nm |
| IR On/Off Control | Auto/Manual |
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| Frame Rate | Main Stream: 2MP(1920*1080),Max 60fps |
| Video Bit Rate | 128 Kbps~16 Mbps |
| ROI | Supported |
| Video stream | Triple streams |
| OSD | Up to 8 OSDs |
| Privacy Mask | 24 areas, Up to 4 areas per scene |
| Digital Noise Reduction | 2D/3D |
| Flip | Normal/Flip Vertical/Flip Horizontal/180°/90°Clockwise/90°Anti-clockwise |
| HLC | Support |
| BLC | Support |
| Defog | Digital defog |
| Audio Compression | G.711A, G.711U |
| Two-way Audio | Support |
| Suppression | Support |
| Sampling Rate | 8kHz |
| Protocols | 802.1x, ARP, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, NTP, PPPoE, QoS, RTCP, RTMP, RTP, SMTP, SNMP, SSL/TLS, TCP, UDP, UPnP |
| Audio In/Out | 1/1 |
| Alarm I/O | 2/1 |
