مشخصات
| Analog Video Input | 8-ch, BNC |
|---|---|
| IP Video Input | 4-ch, each channel up to 8MP |
| Supported Analog Camera Types | Support AHD input: 8MP@15fps 5MP@20fps 4MP@30fps 1080P@30fps 720P@30fps |
| Audio Input | 1-ch, RCA |
| Audio Compression | G.711U |
| Audio Output | 1-ch, BNC |
| VGA Output | 1024×768/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1600×1200/60Hz, 1920x1080p/50Hz, 1920x1080p/60Hz |
| HDMI Output | 1024×768/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1600×1200/60Hz, 1920x1080p/50Hz, 1920x1080p/60Hz, 3840 x 2160/30Hz |
| Synchronous Playback | 8-ch |
| Liveview Display | HDMI/VGA: 1/4/6/8/9/16 |
| Two-way Audio | 1-ch, RCA |
| Incoming Bandwidth | 40Mbps (up to 56Mbps after all analog camera conversion) |
| Outgoing Bandwidth | 64Mbps |
| Remote Users | 128 |
| Protocols | DDNS, DHCP, DNS, HTTP, HTTPS, P2P, SMTP, TCP/IP, UPnP |
| Recording Resolution | 1080p, 4MP Lite, 5MP Lite, 720p, 8MP Lite, CIF |
| Recording Frame Rate | Main stream: 8MP Lite@8fps 5MP Lite @12fps 4MP Lite@15fps 1080P@15fps 720p@30fps |
| Audio Bit Rate | 64Kbps per channel |
| Capability | Analog: 8 x 8MP Lite@8, 8x 5MP Lite@12, 8x 4MP Lite@15, 8x 1080P@15 |
| SATA | 1 SATA interface |
| Capacity | Up to 8TB for each HDD |
| VCA Detection | 8-ch, Ultra Motion Detection (UMD) |
| VCA Search | Behavior Search |
| General Alarm | Motion detection |
| Alert Alarm | Disk Abnormal, Disk Offline, Hard Disk Full, Hard Disk Space Low, Illegal Access, IP Conflict, Network Disconnected, Recording/Snapshot Abnormal |
| Network Interface | 1RJ45 10M/100M self-adaptive Ethernet Interface |
| USB Interface | Rear panel: 2 x USB2.0 |
| RS485 | 1 |
| Alarm In | 4-ch |
| Alarm Out | 1-ch |
| Power Supply | 12V DC, Power Consumption: ≤ 10 W( without HDD ) |
| Working Environment | -10°C ~ +55°C (+14°F ~+131°F ), Humidity ≤ 90% RH(non-condensing) |
| Dimensions | 260mm ×226mm× 47mm (10.2" × 8.9"×1.8") |
| Weight | ≤1.1 Kg |
| Safety certification | CE, FCC, RoHS, UL, WEEE |
