مشخصات
| IP Video Input | 8-ch |
|---|---|
| Analog Video Input | 16-ch, BNC |
| Max IP Video Input | 24-ch |
| Supported Analog Camera Types | Support AHD input: 8MP@15fps, 5MP@20fps, 4MP@30fps, 1080P@30fps, 720P@30fps |
| RCA Audio Input | 1-ch |
| HDMI Output | HDMI: 4K (3840 × 2160)/30 Hz, 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz |
| VGA Output | VGA: 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz |
| Video Output | 1-ch |
| RCA Audio Output | 1-ch |
| Liveview Display | HDMI/VGA: 1/4/6/8/9/25 |
| Recording Resolution | 1080p, 4MP Lite, 5MP Lite, 720p, 8MP Lite, D1 |
| Recording Frame Rate | Main stream: 8MP Lite@8fps Sub stream: D1@8fps |
| Audio Sample Rate | 8 kHz, 16 bit per channel |
| Audio Bit Rate | 64Kbps per channel |
| Decoding Capability | Analog: 16 x 8MP Lite@8, 16 x 3K Lite@12, 16 x 5MP Lite@12, 16 x 4MP Lite@15, 16 x 1080P@15, 16 x 720@30 |
| Two-way Audio | 1-ch,RCA(Using the audio input and output) |
| Incoming Bandwidth | 80Mbps (Up to 112Mbps after all analog channel conversion) |
| Outgoing Bandwidth | 160Mbps |
| Remote Users | 128 |
| Protocols | DDNS, DHCP, DNS, HTTP, HTTPS, NTP, P2P, SMTP, TCP/IP, UPnP |
| Analog Smart by XVR | Ultra Motion Detection (UMD), SIP (Intrusion Detection, Cross Line Detection, Enter Area, Leave Area) , Face Detection |
| Smart by IPC | Auto Tracking, Defocus Detection, Face Detection, Object Left Behind, Object Removed, People Flow Counting, Scene Change Detection, SIP (Intrusion Detection, Cross Line Detection, Enter Area, Leave Area) |
| VCA Search | Behavior Search, Face Search, People Counting Report |
| Smart Functions by XVR | 4-ch (SIP), 2-ch (Face Detection), 16-ch (UMD) |
| Smart Functions by IP Camera | 4-ch (SIP), All channels (up to 4 images/s in total) Face Detection |
| General Alarm | Motion |
| Alert Alarm | Disk Abnormal, Disk Offline, Hard Disk Full, Hard Disk Space Low, Illegal Access, IP Conflict, Network Disconnected, Recording/Snapshot Abnormal |
| SATA | 2 SATA interfaces |
| Capacity | Up to 24 TB for each HDD |
| Network Interface | 1RJ45 10 M/100 M/1000 M self-adaptive Ethernet Interface |
| USB Port | Rear panel: 1 × USB3.0, Front panel: 1 × USB2.0 |
| RS485 | 1 |
| Alarm In | 4-ch |
| Alarm Out | 1-ch |
| Power Supply | DC 12V/3.3 A |
| Working temperature | -10°C~+55 °C(+14°F~+131°F) |
| Humidity | ≤ 90% RH (non-condensing) |
| Max power consumption | ≤ 12W |
| Weight | ≤2.0 Kg |
| Dimensions | 380mm ×326mm× 53mm (15.0" × 12.8"×2.1") |
| Safety certification | CE, FCC, RoHS, UL, WEEE |
| CE | EN 55032, EN 55035, EN 61000-3-3, EN IEC 61000-3-2 |
| FCC | Part15 Subpart B |
