مشخصات
| Analog Video Input | BNC, ch-16 |
|---|---|
| IP Video Input | 8-ch(up to 16-ch after analog camera conversion) |
| Supported Analog Camera Types | Support AHD input: 5MP@12fps 4MP@15fps 1080P@30fps 720P@30fps |
| Audio Input | 1-ch, RCA |
| Audio Compression | G.711U |
| Incoming Bandwidth | 40Mbps (up to 56Mbps after all analog camera conversion) |
| Outgoing Bandwidth | 64Mbps |
| Remote Users | 128 |
| Protocols | DDNS, DHCP, DNS, HTTP, HTTPS, P2P, SMTP, TCP/IP, UPnP |
| HDMI/VGA Output | VGA Output: 1920×1080/60Hz, 1920×1080/50Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz |
| Audio Output | 1-ch, RCA |
| Synchronous Playback | HD:8-ch, SD:16-ch |
| Liveview Display | 1, 16, 25, 4, 6, 8, 9 |
| Two-way Audio | 1-ch, RCA |
| Recording Resolution | 1080p, 1080P Lite, 4MP Lite, 5MP Lite, 720p, CIF |
| Frame Rate | Main stream: 5MP Lite@6fps, 4MP Lite@8fps, 1080P Lite@12fps, 720P@12fps, Sub stream: D1@6fps, D1@8fps, D1@12fps, D1@12fps |
| Sampling Rate | 16 bit per channel, 8kHz |
| Audio Bit Rate | 64Kbps per channel |
| SATA | 1 SATA interface |
| Capacity | Up to 8TB for each HDD (The maximum HDD capacity varies with environment temperature) |
| General Alarm | Motion detection |
| Alert Alarm | Disk Abnormal, Disk Offline, Illegal Access, IP Conflict, Network Disconnected, Recording Abnormal, Running Out of Space, Space Used Up |
| Network Interface | 1RJ45 10M/100M self-adaptive Ethernet Interface |
| USB Interface | Rear panel:2 x USB2.0 |
| Serial Interface | 1 *RS485 |
| Power Supply Type | 12V DC, Power Consumption: ≤ 10 W( without HDD ) |
| Working Environment | -10°C ~ +55°C (+14°F ~+131°F ), Humidity ≤ 90% RH(non-condensing) |
| Dimensions | 260mm × 229mm × 47mm |
| Weight | ≤ 1.1Kg |
| Safety certification | CE, FCC, WEEE |
